ELYSIUM 19'6 Family
Luxury meets durability - enjoy all the creature comforts you've come to love without compromise on strength.
ATM: 3500KG*
OVERALL LENGTH: 8.7m
APPROX TRAVEL HEIGHT: 3.12m
TRACK WIDTH: 2.0m
WATCH OUR VIDEO
Internal walk through
Floor Plan
Configurations can change depending on model! Come visit us on the Sunshine Coast to see this in person.
Vision Elysium 19' Family
Gallery
HIGHLIGHTED FEATURES
(THERE IS MORE!)
- Huge external kitchen, hot & cold tap, shelves, pantry and powerpoints
- Garmin Connect Dual Tablet (mobile and fixed) for smart system control including but not limited to;
- Lights internal and external, all dimmable
- Airbag Control, manual, wireless, and auto levelling either on site or multi situation ride height - 270 litre fridge / freezer
- Reverse cycle air-conditioner
- Induction cooktops, plus below counter multi function microwave oven - everything you need to cook inside and outside your van
- Endless solar and battery with powerpoints at all logical locations
- Dedicated fans, reading lights and charging points for queen size master bed
- Front storage box with dual sliding shelves and firewood rack / shelf
- Dual hot and cold outdoor showers
7 Year Limited Warranty on all Models
Feature List
Electrical
- Garmin Connect 50 Digital Switching System via Dual Tablets, one fixed and one mobile usable from vehicle for air bags and dust reduction system
- Massive 460ah lithium battery
- 3000W/100A Enerdrive Inverter/Charger Unit
- 1000W solar
- Enerdrive 40amp DC-DC battery charger with MPPT
- Twin enerdrive 40A MMPT Solar Controllers (Solar array divided into two MPPT's)
- Enerdrive ePro PLUS battery monitor
- White/amber external dimmable lights, both sides and rear
- Front external LED spotlight on swivel mount
- Power Pack Upgrade - From 1000W to 1200W solar and add extra 460Ah lithium battery
Appliances
- 270 Litre fridge / freezer
- Reverse cycle air conditioner
- Gusto Dust Reduction System
- Dual burner induction internal cooktop
- Huge external kitchen with single induction burner, shelves hot and cold tap, Garmin Dock, 12v cig, USB's, double 240v, antenna socket and tv bracket
- 4 in 1 microwave, grill, convection oven and steamer
- Reversing camera - optional dual lens, single as standard
- Roll out awning
- 2 x 12V fans in main bed area
- Bedside charging points USB 240V with LED reading lights
- Dimmable roof, overheads and floor warm LED strips
- Front load washing machine
- 24 inch TV, optional roof top antenna
- Optional TRUMA Gas heater controlled by Vario Digital Climate Control Panel
Plumbing
- 3 x 90 litre fresh water tanks (270 litres total)
- 85 litre grey water tank plus 16 litre urine tank separately plumbed
- Dual external hot / cold showers, either side of tool box
- Water tank manifold allowing all tanks to be filled and drained independently
- TRUMA instant gas hot water system controlled by VARIO Digital Control Panel
- Generous internal shower with channel drain
- Vision RV's simple ZERO SMELL compost toilet with urine tank plumbed to separate grey tank partition and external outlet
DECALS / LIVERY
- Black Raptor Coated base protection strip around shell - installed post van assembly to ensure superior sealing. Optional rear bar Raptor Coating available
- High grade 3M Decals - holographic black camo and charcoal with colour changing pearl effect
- Optional WAABINY Indigenous artwork - dark or light versions - meaning 'playtime'
- Optional KIAH LEUMEAH Indigenous artwork - Dark - meaning 'Beautiful place, here I rest'
Chassis
- Hot dipped galvanised chassis - 150mm x 50mm
- Tandem 3500kg ATM with Cruisemaster D035 coupling (pre-approved to upgrade to 4500kg ATM and D045)
- Heavy duty trailing arm independent airbag suspension, twin ARB shock absorbers per wheel
- Ventilated disc brakes, large parallel bearings
- Large off-road wheels and tyres (285/70/R17) + 35 offset allows for easy matching to tow vehicle. Five or six studs available with a 35" optional upgrade available
- Spare wheel and tyre with upgrade available for second spare
- Heavy duty centre mounted jockey wheel
- Heavy duty rear recovery points of rear chassis rails and modular rear bar for Vision's range of bolt on accessories
- Heavy duty rear bar - Chassis extension providing superior departure angle and unrivalled rear protection strength and to facilitate mounting of accessories
EXTERNAL FEATURES
- Super strong monocoque composite shell construction providing unrivalled strength, durability, insulation standards and repairability
- Single piece honeycomb composite floor
- Unrivalled electrical assist door, connected to remote central locking for best in industry sealing and security
- Air compressor with outlet for tyre inflation and cleaning
- Dual jerry can holders and twin 4kg gas bottles in front box
- Front storage box with dual sliding shelves and firewood rack, pole carrier and tapered front to act as a stone shield. Raptor coated for superior durability.
- Industry leading heavy duty aluminium extrusion joining all external walls
- Entire van including all cabinetry is 100% timber free construction
- Airbag Control, manual, wireless, and auto levelling either on site or multi situation ride height
Internal Features
- Double glazed euro styled windows
- Aluminium cabinetry - laser cut, folded and powder coated
- Lightweight honeycomb door and draw facias
- Solid surface commercial grade acrylic bench and table tops
- Soft close draw runners
- Stylish automotive leather lounges in a selection of colours
- Class leading storage
- Premium queen size pillow-top mattress
- Electric lift under bed storage compartment
- Auto locking door
Elysium MY2025 Feature update
