NIRVANA 16B POPTOP / HARDTOP
More bench space and more storage in our luxury RV that will go anywhere your vehicle can!
ATM: 3500KG
TARE 2500KG*
OVERALL LENGTH: 7.54m / TRACK WIDTH: 1.78m
APPROX TRAVEL HEIGHT: 2.6m
WATCH OUR VIDEO
Floor Plan
Configurations can change depending on model! Come visit us on the Sunshine Coast to see this in person.
Vision RV 16B POPTOP / HARDTOP
Gallery
HIGHLIGHTED FEATURES
(THERE IS MORE!)
- Huge external kitchen, 3 burner cooker, sink with hot & cold tap, shelves, pantry nooks, slide out pantry draws and powerpoints
- Vitrifrigo 150 litre fridge / freezer
- Reverse cycle air-conditioner
- Endless solar and battery with powerpoints at all logical locations
- Dedicated fans, reading lights and charging points for King size master bed
- Front storage box with dual sliding shelves and firewood rack / shelf
7 Year Limited Warranty on all Models
Feature List
Electrical
- POPTOP: 460Ah lithium battery, 3000W/100A Enerdrive Inverter / Charger, 990W solar
- HARDTOP: 460Ah lithium battery, 3000W/100A Enerdrive Inverter / Charger, 800W solar
- Enerdrive 40amp DC-DC battery charger with MPPT
- Single Enerdrive 40A MPPT Solar Controller
- Enerdrive ePro PLUS battery monitor
- White/amber external lights, both sides and rear
- Front external LED spotlight on swivel mount
Appliances
- Huge external kitchen, 3 burner cooker, sink with hot and cold tap, shelves, pantry nooks, slide out pantry draws, 12V cig, USB's and double 240v
- Vitrifrigo 150 litre upright compressor fridge / freezer
- POPTOP Optional Reverse cycle air conditioner. HARDTOP as standard
- Optional Gusto Dust Reduction System
- Optional Induction cooktop
- Reversing camera - optional dual lens, single as standard
- Fiamma / Cassette awning
- 2 x 12V fans in main bed area
- Bedside charging points USB 240V with LED reading lights
- Individual touch LED strips throughout van
- Optional front load washing machine
- Optional 24 inch TV with roof top antenna
- Optional TRUMA Gas heater controlled by Vario Digital Climate Control Panel
Plumbing
- 3 x 90 litre fresh water tanks (270 litres total)
- Grey tank divided into 75l grey water tank plus 14 litre urine tank separately plumbed
- Dual external hot / cold showers, either side of tool box
- Water tank manifold allowing all tanks to be filled and drained independantly
- TRUMA instant gas hot water system controlled by VARIO Digital Control Panel
- Internal shower with channel drain
- Vision RV's simple ZERO SMELL compost toilet with urine tank plumbed to separate grey tank partition and external outlet
DECALS / LIVERY
- Black Raptor Coated base protection strip around shell - installed post van assembly to ensure superior sealing.
- High grade 3M Decals - holographic black camo and charcoal with colour changing pearl effect
- WAABINY Indigenous artwork - dark or light versions - meaning 'playtime'
- KIAH LEUMEAH Indigenous artwork - Dark - meaning 'Beautiful place, here I rest'
Chassis
- Hot dipped galvanised chassis - 150mm x 50mm
- Dual axle 3500kg ATM with Cruisemaster D035 coupling (up to 900kg payload subject to model and options fitted)
- Heavy duty trailing arm independent airbag suspension, twin ARB shock absorbers per wheel
- Ventilated disc brakes, large parallel bearings
- Large off-road wheels and tyres (285/70/R17) + 35 offset allows for easy matching to tow vehicle. Five or six studs available with a 35" optional upgrade available
- Spare wheel and tyre with upgrade available for second spare
- Heavy duty centre mounted jockey wheel
- Heavy duty rear recovery points on rear chassis rails
- Heavy duty rear bar - Chassis extension providing superior departure angle and unrivalled rear protection strength and to facilitate mounting of accessories
EXTERNAL FEATURES
- Super strong monocoque composite shell construction providing unrivalled strength, durability, insulation standards and repairability
- Aluminium entry door with security and fly screen
- Single piece honeycomb composite floor
- Air compressor with outlet for tyre inflation and cleaning
- Dual jerry can holders and twin 4kg gas bottles in front box
- Front storage box with dual sliding shelves and firewood rack, pole carrier and tapered front to act as a stone shield. Raptor coated for superior durability.
- Industry leading heavy duty aluminium extrusion joining all external walls
- Entire van including all cabinetry is 100% timber free construction
- Electric roof raiser
- Wireless, remote airbags to safely navigate challenging terrain with variable loads
Internal Features
- Double glazed euro styled windows
- Aluminium cabinetry - laser cut, folded and powder coated
- Solid surface commercial grade acrylic bench
- Stylish automotive leather lounges
- Class leading storage
- Durable white poptop with several zippable windows to allow maximum ventilation
- Premium king size pillow-top mattress
