NIRVANA 16B POPTOP / HARDTOP
More bench space and more storage in our luxury RV that will go anywhere your vehicle can!
ATM: 3500KG
TARE 2500KG*
OVERALL LENGTH: 7.54m / TRACK WIDTH: 1.78m
APPROX TRAVEL HEIGHT: 2.6m
WATCH OUR VIDEO
Floor Plan
Configurations can change depending on model! Come visit us on the Sunshine Coast to see this in person.
Vision RV 16B POPTOP / HARDTOP
Gallery
HIGHLIGHTED FEATURES
(THERE IS MORE!)
- Huge external kitchen, 3 burner cooker, sink with hot & cold tap, shelves, pantry nooks, slide out pantry draws and powerpoints
- Thetford 174 litre upright compressor fridge / Ice Box
- Reverse cycle air-conditioner
- Endless solar and battery with powerpoints at all logical locations
- Dedicated fans, reading lights and charging points for King size master bed
- Front storage box with dual sliding shelves and firewood rack / shelf
7 Year Limited Warranty on all Models
Feature List
Electrical
- 460Ah lithium battery, 3000W/120A inverter / Victron charger - upgradable to 920ah
- 1320w Solar (12 x 110w Ultra thin lightweight panels)
- Victron 50amp DC-DC battery charger
- Bluetooth Compatible Electrical System
- 2 x Victron 50A MPPT Roof Solar Controller
- Rear grey anderson input output 50amp (requires regulated solar blanket)
- Victron battery monitor w/ phone app
- White/amber external lights, both sides and rear
- Front external LED spotlight on swivel mount
Appliances
- Huge external kitchen, 2 burner cooker, sink with hot and cold tap, shelves, pantry nooks, slide out pantry draws, 12V cig, USB's and double 240v
- Thetford 174 litre upright compressor fridge / Ice Box
- Reverse cycle air conditioner - Standard in hardtop
- Gusto Dust Reduction System - optional
- Induction cooktop - optional
- Reversing camera - optional dual lens, single lens as standard
- Fiamma / Cassette awning
- 12V fans for each occupant (2x couples layout up to 5x for triple bunk)
- Bedside charging points USB with LED reading lights - 240v standard for hard top only
- Individual touch LED strips throughout van
- Front load washing machine - optional in tunnel boot
- 24 inch TV with portable antenna - optional
- TRUMA Gas heater controlled by Vario Digital Climate Control Panel - optional
Plumbing
- 3 x 90 litre fresh water tanks (270 litres total)
- Water tank manifold allowing all tanks to be filled and drained independently
- Dual external hot / cold showers, either side of tool box
- Grey tank 86 litre grey water tank plus 14 litre urine tank separately plumbed
- TRUMA instant gas hot water system w/ Truma CP Plus Panel
- Internal shower with channel drain
- Vision RV's simple compost toilet with urine tank plumbed to separate black tank and external outlet
DECALS / LIVERY
- Black Raptor Coated base protection strip around shell - installed post van assembly to ensure superior sealing.
- High grade 3M Decals - holographic black camo and charcoal with colour changing pearl effect
- WAABINY Indigenous artwork - dark or light versions - meaning 'playtime'
- KIAH LEUMEAH Indigenous artwork - Dark - meaning 'Beautiful place, here I rest'
Chassis
- Hot dipped galvanised chassis - 150mm x 50mm
- Dual axle 3500kg ATM with Cruisemaster D035 coupling
- Heavy duty trailing arm independent airbag suspension, twin shock absorbers per wheel
- Ventilated disc brakes
- Japanese bearings
- Large off-road wheels and tyres (285/70/R17) + 35 offset allowing for easy matching to tow vehicle. Five or six studs available
- Spare wheel and tyre with upgrade available for second spare - optional
- Heavy duty centre mounted jockey wheel
- Heavy duty rear recovery points on rear chassis rails
- Heavy duty rear bar - chassis extension providing superior departure angle and unrivalled rear protection strength and to facilitate mounting of accessories
EXTERNAL FEATURES
- Super strong monocoque composite shell construction providing unrivalled strength, durability, insulation standards and repairability
- Aluminium entry door with security and fly screen
- Single piece honeycomb composite floor
- Air compressor with outlet for tyre inflation and cleaning
- Dual jerry can holders and twin 4kg gas bottles in front box
- Raptor coated front storage box with dual sliding shelves and firewood rack, pole carrier and tapered front to act as a stone shield
- Industry leading heavy duty aluminium extrusion joining all walls
- Entire van including all cabinetry is 100% timber free construction
- Electric roof raiser - pop top only
- Wireless, remote airbags with variable load capability
Internal Features
- Flat panel Euro Style windows with block out blind and flyscreen
- Aluminium cabinetry - laser cut, folded and powder coated
- Solid surface commercial grade acrylic bench
- Stylish automotive leather lounges
- Class leading storage
- Durable white poptop with several zippable windows to allow maximum ventilation - pop top
- Generous head-height storage - hard top
- Premium Caravan King Size pillow-top mattress 203cm x 175cm
