ELYSIUM 21'6 FAMILY
Luxury meets durability - enjoy all the creature comforts you've come to love without compromise on strength.
ATM: 4500KG
OVERALL LENGTH: 9.2m
APPROX TRAVEl HEIGHT: 3.12
TRACK WIDTH: 2.0m
VISION RV OFF ROAD TESTING
Floor Plan
Configurations can change depending on model! Come visit us on the Sunshine Coast to see this in person.
Vision Elysium 21'6 Family
Gallery
HIGHLIGHTED FEATURES
(THERE IS MORE!)
- Huge external kitchen, 3 burner cooker, sink with hot & cold tap, shelves, pantry nooks, slide out pantry draws and powerpoints
- Garmin Connect Dual Tablet for smart system control including lights
- Massive 274 litre, fridge / freezer
- Reverse cycle air-conditioner
- Induction Cooktop, plus 4 in 1 microwave, grill, convention oven and steamer
- Endless solar and battery with powerpoints at all logical locations
- Dedicated fans, reading lights and charging points for Queen size master bed
- Front storage box with dual sliding shelves and firewood rack / shelf
7 Year Limited Warranty on all Models
Feature List
Electrical
- Garmin Connect 50 Digital Switching System via Dual Tablets, one fixed and one mobile usable from vehicle for air bags and dust reduction system + App
- Massive 460ah lithium battery standard, upgradable to 920ah
- 3000W/120A Victron inverter charger unit
- 1540W solar 14 panels upgradable to 1760 solar 16 panels
- 1760W solar 16 panels
- Victron 50amp DC-DC battery charger
- 3x Victron 50A MMPT solar controllers (solar array divided into three MPPT's)
- Victron Smart Shunt battery monitor displayed in Garmin & Cervo GX Communication centre with remote access
- White & amber external dimmable lights, both sides and rear
- Front external LED spotlight on swivel mount
Appliances
- Huge external kitchen with dual burner, shelves hot and cold tap, Garmin Dock, 12v cig, USB's, double 240v, antenna socket and tv bracket
- Massive 274 litre, fridge / freezer
- Reverse cycle air conditioner
- Gusto Dust Reduction System
- 3 in 1 microwave, grill & convection oven
- Reversing camera - single lens as standard, dual lens -optional
- Roll out awning
- 12V fans for each occupant (2x couples layout up to 5x for triple bunk)
- Bedside charging points USB 240V with LED reading lights
- Dimmable roof, overheads and floor warm LED strips
- Front load washing machine
- 24 inch TV with roof top antenna - optional
- TRUMA Gas heater controlled by Vario Digital Climate Control Panel - optional
Plumbing
- 3 x 90 litre fresh water tanks (270 litres total) + 1 x 90 litre optional extra
- 86 litre grey water tank plus 14 litre urine tank separately plumbed
- Dual external hot / cold showers, either side of tool box
- Water tank manifold allowing all tanks to be filled and drained independently
- TRUMA instant gas hot water system controlled by VARIO Digital Control Panel
- Generous internal shower with channel drain
- Vision RV's simple compost toilet with urine tank plumbed to separate black tank and external outlet
DECALS / LIVERY
- Black Raptor Coated base protection strip around shell - installed post van assembly to ensure superior sealing. Optional rear bar Raptor Coating available
- High grade 3M Decals - holographic black camo and charcoal with colour changing pearl effect
- Optional WAABINY Indigenous artwork - dark or light versions - meaning 'playtime'
- Optional KIAH LEUMEAH Indigenous artwork - Dark - meaning 'Beautiful place, here I rest'
Chassis
- Hot dipped galvanised chassis - 150mm x 50mm
- Tandem axle 3500kg ATM with Cruisemaster D035 coupling (pre-approved to upgrade to 4500kg ATM and D045 Chains and Jockey wheel to match)
- 4500kg ATM and D045 Chains and Jockey wheel to match
- Heavy duty trailing arm independent airbag suspension, twin shock absorbers per wheel
- Ventilated disc brakes
- Japanese bearings
- Large off-road wheels and tyres (285/70/R17) + 35 offset allows for easy matching to tow vehicle. Five or six studs available with a 35" optional upgrade
- Spare wheel and tyre with upgrade available for second spare
- Heavy duty centre mounted jockey wheel
- Heavy duty rear recovery points of rear chassis rails and modular rear bar for Vision's range of bolt on accessories
- Heavy duty rear bar - Chassis extension providing superior departure angle and unrivalled rear protection strength and to facilitate mounting of accessories
EXTERNAL FEATURES
- Super strong monocoque composite shell construction providing unrivalled strength, durability, insulation standards and repairability
- Single piece honeycomb composite floor
- Unrivalled electrical assist door, connected to remote central locking for best in industry sealing and security
- Air compressor with outlet for tyre inflation and cleaning
- Dual jerry can holders and twin 4kg gas bottles in front box
- Front storage box with dual sliding shelves and firewood rack, pole carrier and tapered front to act as a stone shield. Raptor coated for superior durability.
- Industry leading heavy duty aluminium extrusion joining all external walls
- Entire van including all cabinetry is 100% timber free construction
- Airbag Control: manual/wireless and auto levelling when stationary, multi situation ride height
Internal Features
- Flat panel Euro Style windows with block out blind and flyscreen
- Aluminium cabinetry - laser cut, folded and powder coated
- Lightweight honeycomb door and draw facias
- Solid surface commercial grade acrylic bench and table tops
- Soft close draw runners
- Stylish automotive leather lounges in a selection of colours
- Class leading storage
- Premium caravan queen size pillow-top mattress
- Electric lift under bed storage compartment (for North South Bed configuration)
- Remote central locking door for reliable seal and security
Elysium MY2025 Feature update
