NIRVANA 16C POPTOP or HARDTOP

Compact luxury designed to go anywhere your vehicle can - including an indulgent seperate shower and toilet!

ATM: 3500KG
TARE 2500KG*
OVERALL LENGTH: 7.52m / APPROX TRAVEL HEIGHT: 2.6m POP / 3.12 HARD
OVERALL WIDTH: 1.78m

WATCH OUR VIDEO

Floor Plan

Configurations can change depending on model! Come visit us on the Sunshine Coast to see this in person.

HIGHLIGHTED FEATURES

(THERE IS MORE!)

  • Huge external kitchen, 3 burner cooker, sink with hot & cold tap, shelves, pantry nooks, slide out pantry draws and powerpoints
  • Seperate shower and toilet with minimal impact on internal space
  • Thetford 105ltr fridge / freezer
  • Hardtop standard reverse cycle air-conditioner, poptop optional
  • Endless solar and battery with powerpoints at all logical locations
  • Dedicated fans, reading lights and charging points for King size master bed
  • Front storage box with dual sliding shelves and firewood rack / shelf

7 Year Limited Warranty on all Models

Feature List

  • 460Ah lithium battery, 3000W/120A inverter / Victron charger - upgradable to 920ah
  • 1320w Solar (12 x 110w Ultra thin lightweight panels)
  • Victron 50amp DC-DC battery charger
  • Bluetooth Compatible Electrical System
  • 2 x Victron 50A MPPT Roof Solar Controller
  • Rear grey anderson input output 50amp (requires regulated solar blanket)
  • Victron battery monitor w/ phone app
  • White/amber external lights, both sides and rear
  • Front external LED spotlight on swivel mount

  • Huge external kitchen, 2 burner cooker, sink with hot and cold tap, shelves, pantry nooks, slide out pantry draws, 12V cig, USB's and double 240v
  • Thetford 105 litre upright compressor fridge / Ice Box - B Layout - 174l
  • Reverse cycle air conditioner - Standard in hardtop
  • Gusto Dust Reduction System - optional
  • Induction cooktop - optional
  • Reversing camera - optional dual lens, single lens as standard
  • Fiamma / Cassette awning
  • 12V fans for each occupant (2x couples layout up to 5x for triple bunk)
  • Bedside charging points USB with LED reading lights - 240v standard for hard top only
  • Individual touch LED strips throughout van
  • Front load washing machine - optional in tunnel boot
  • 24 inch TV with portable antenna - optional
  • TRUMA Gas heater controlled by Vario Digital Climate Control Panel - optional

  • 3 x 90 litre fresh water tanks (270 litres total)
  • Water tank manifold allowing all tanks to be filled and drained independently
  • Dual external hot / cold showers, either side of tool box
  • Grey tank 86 litre grey water tank plus 14 litre urine tank separately plumbed
  • TRUMA instant gas hot water system w/ Truma CP Plus Panel
  • Internal shower with channel drain
  • Vision RV's simple compost toilet with urine tank plumbed to separate black tank and external outlet

  • Black Raptor Coated base protection strip around shell - installed post van assembly to ensure superior sealing.
  • High grade 3M Decals - holographic black camo and charcoal with colour changing pearl effect
  • Optional WAABINY Indigenous artwork - dark or light versions - meaning 'playtime'
  • Optional KIAH LEUMEAH Indigenous artwork - Dark - meaning 'Beautiful place, here I rest'

  • Hot dipped galvanised chassis - 150mm x 50mm
  • Dual axle 3500kg ATM with Cruisemaster D035 coupling
  • Heavy duty trailing arm independent airbag suspension, twin shock absorbers per wheel
  • Ventilated disc brakes
  • Japanese bearings
  • Large off-road wheels and tyres (285/70/R17) + 35 offset allowing for easy matching to tow vehicle. Five or six studs available
  • Spare wheel and tyre with upgrade available for second spare - optional
  • Heavy duty centre mounted jockey wheel
  • Heavy duty rear recovery points on rear chassis rails
  • Heavy duty rear bar - chassis extension providing superior departure angle and unrivalled rear protection strength and to facilitate mounting of accessories

  • Super strong monocoque composite shell construction providing unrivalled strength, durability, insulation standards and repairability
  • Aluminium entry door with security and fly screen
  • Single piece honeycomb composite floor
  • Air compressor with outlet for tyre inflation and cleaning
  • Dual jerry can holders and twin 4kg gas bottles in front box
  • Raptor coated front storage box with dual sliding shelves and firewood rack, pole carrier and tapered front to act as a stone shield
  • Industry leading heavy duty aluminium extrusion joining all walls
  • Entire van including all cabinetry is 100% timber free construction
  • Electric roof raiser - pop top only
  • Wireless, remote airbags with variable load capability

  • Flat panel Euro Style windows with block out blind and flyscreen
  • Aluminium cabinetry - laser cut, folded and powder coated
  • Solid surface commercial grade acrylic bench
  • Stylish automotive leather lounges
  • Class leading storage
  • Durable white poptop with several zippable windows to allow maximum ventilation - pop top
  • Generous head-height storage - hard top
  • Premium Caravan King Size pillow-top mattress 203cm x 175cm
